Lasers
HighLight DL Series
Use fiber-coupled, multi-kW diode lasers for efficient, cladding, additive manufacturing, heat-treatment, and laser assisted bonding.
These lasers combine high output power, the convenience of fiber delivery, and numerous optional accessories to make it easy to configure for specific tasks. Plus, their conduction-cooled diodes do not require deionized cooling water.
HighLight DL Series Diode Lasers Overview
Get exactly the power, beam output, and package characteristics you need from this diverse product offering.
Product Specifications
Product Series |
Output Power (kW) |
Beam Quality BPP (mm*mrad) |
Wavelength Range (nm) |
Key Feature |
DL-HP |
4 - 8 |
100 |
940 - 1020 |
Up to 8kW |
DL-HPR |
1 - 4 |
100 or 60 |
940 - 1020 |
19” Rack Mounted |
DL-HPS |
1 - 4 |
100 or 60 |
940 - 1020 |
System with Integrated Chiller Easy Setup |
DL-HQ |
1 - 2 |
40 |
980 |
Single Wavelength |
All diode lasers have a fiber connector for plug and play fiber connection and a homogeneous beam profile. |
||||
