带 AR 涂层的窗口片
使用这些带有防反射涂层的精密平面平行窗口片,在最大限度降低损耗和波前畸变的情况下传输红外光和激光束。
窗口片在光学系统中经常使用,通常用于环境隔离,例如密封真空或高压单元。红外材料的折射率高,因此为了减少反射损失,就必须使用增透涂层。
By providing your information and clicking ‘Subscribe’, you opt-in to receiving periodic email marketing communications from Coherent Corp. and understand that your personal data will be processed in accordance with our Privacy Policy and that our Terms apply. You may opt-out of marketing emails sent by us at any time by clicking the unsubscribe link in any marketing email you receive.
带 AR 涂层的 ZnSe 窗口片选择
从我们的标准窗口片产品系列中进行选择,或准确指定您需要的组件。Coherent 拥有广泛的光学制造和涂层能力。
型号 |
直径 (mm) |
厚度 (mm) |
0.63μm 波长表面形貌(功率/不规则度) |
表面质量 |
每个表面反射率 (%) |
185217 |
6.35 |
2.03 |
1.0 条纹/0.5 条纹 |
20-10 |
< 0.20 |
568604 |
9.53 |
2.03 |
|||
162879 |
12.7 |
2.03 |
|||
457172 |
19.05 |
2.03 |
|||
735199 |
25.4 |
2.03 |
|||
617035 |
25.4 |
3.05 |
|||
834076 |
27.94 |
3.05 |
|||
184651 |
38.1 |
3.05 |
|||
883636 |
50.8 |
5.08 |
|||
243559 |
63.5 |
6.35 |
|||
616847 |
76.2 |
6.35 |
