Beamsplitter Cubes
Split and recombine laser beams or broadband sources with these beamsplitter cubes that offer both polarization insensitivity and high throughput.
Coherent non-polarizing beamsplitter cubes use a metallic–dielectric coating that maintains transmission and reflection of the s- and p-polarization states to within 5% of each other, thus minimizing the polarization sensitivity of an optical system.
By providing your information and clicking ‘Subscribe’, you opt-in to receiving periodic email marketing communications from Coherent Corp. and understand that your personal data will be processed in accordance with our Privacy Policy and that our Terms apply. You may opt-out of marketing emails sent by us at any time by clicking the unsubscribe link in any marketing email you receive.
Beamsplitter Cube Capabilities
Choose size, wavelength range, and anti-reflection coating options to meet your exact requirements.
Typical Beamsplitter Specifications |
|
Material |
N-BK7 or fused silica |
Flatness |
λ/4 @ 632.8 nm |
Surface Quality |
40–20 |
Beam Deviation |
<3 arc minute |
Incidence Angle |
0°±3° |
Transmission |
Ts = Tp = 50%±5% |
Reflection |
Rs = Rp 50%±5% |
Coating |
Non-polarizing beamsplitter coating on the hypotenuse Optional AR coating on input/output faces |
